CNC turning
Okuma Multus U 4000-1SC2000
is a high-performance multifunctional five-axis turning/milling centre with a rotating tool head. The machine is equipped with a lunette and tailstock.
The machine functions are controlled by a CNC control system, which also allows machining of spatially complex shapes, where the tool follows a path created as output from a 3D CAM program.
.jpeg)
| Technical data CNC Okuma Multus U 4000-1SC2000 | |
|---|---|
| Maximum orbital diameter | 630 mm |
| Maximum machined diameter | 630 mm |
| Maximum Y-axis milling | 300 mm |
| Maximum length | 1 840 mm |
| Diameter at lunette | 90-320 mm |
Carousel SKIQ 8 CNC
The machine is designed for precision vertical turning work, especially in piece and small batch production. The main machining operation is the turning of surface, face and internal surfaces, both cylindrical and conical or spherical.
It is also possible to drill and bore central holes and cut external and internal threads.
| Technical data SKIQ 8 CNC carousel | |
|---|---|
| Clamping plate diameter | 800 mm |
| Maximum working diameter | 1 100 mm |
| Maximum working height | 630 mm |
| Maximum workpiece weight | 4 000 kg |
Carousel SKIQ 12 CNC B
The machine is designed for precise vertical turning work, especially in piece and small batch production. The main machining operation is the turning of surface, face and internal surfaces, both cylindrical and conical or spherical.
It is also possible to drill and bore central holes and cut external and internal threads.
| Technical data of the SKIQ 12 CNC B carousel | |
|---|---|
| Clamping plate diameter | 1 250 mm |
| Maximum working diameter | 1 300 mm |
| Maximum working height | 700 mm |
| Maximum workpiece weight | 12 000 kg |
Hermle C42 U MT
is a milling and turning centre, like the C 42 / C 42 MT GEN2, meets all requirements also in the field of automation.
It starts with the compatible PW 850 pallet changer, which can handle components and pallets with particularly large dimensions.
.jpeg)
| Technical data Hermle C42 U MT | |
|---|---|
| Maximum working diameter | 800 mm |
| Maximum machined diameter | 800 mm |
| Maximum Z-axis height | 520 mm |
| Maximum speed | 15 000 rpm |
| Number of pallets | 5 |
| Maximum table load | 700 kg |
Hermle C 52 U MT
is a high-performance vertical five-axis milling centre with tilting rotary table and pallet exchange.
The CNC control system allows machining even spatially complex shapes, where the tool follows a path created as output from a 3D CAM program.
| Technical data Hermle C 52 U MT | |
|---|---|
| Runway | 1 000 x 1 100 x 750 mm |
| Maximum table load | 2 000 kg |
| Spindle speed | 14 000 rpm |
| Body | Ø 1 100 / H 810 mm |
| Vertical distance of table | max. 950 mm |
| Collision ring | Ø 1 290 mm |
| Tilting turntable | Ø 1 000 mm |
| Number of pallets | 2 |
| Maximum table load during turning | 1 000 kg |
| Maximum table load for milling | 2 000 kg |
